The three-dimensional multi-stage environmental protection screen is a new type of high standard screening device. This series of environmental protection screening machines is designed with advanced foreign design concepts, unique design, complete series spectrum, high screening accuracy, environmental protection and energy saving, fast replacement of screen mesh, negative pressure operation, good insulation, low noise and other characteristics. This series of screening machines currently has six specifications: GLSF1000-6000 series, with a screen surface that can achieve 4-6 layers, a screen hole size of 1.2-100mm to choose from, and a classification of 5-7 different materials. The special screen surface layout allows for higher screen utilization, fast switching of material classification, and simpler screen replacement. The processing capacity can reach 50-800t/h per hour. Compliant with the precise grading of sand and gravel aggregates and ultrafine granular materials, it can effectively meet the needs of environmentally friendly screening and grading for road asphalt mixing plants and building type machine-made sand systems.

This series of three-dimensional multi-level environmental protection screens adopts advanced design concepts and finite element force analysis calculation methods, and is equipped with advanced CNC machining, process and detection equipment. Each screening machine is equipped with an APP intelligent control system, which is interlocked with remote centralized control, online fault diagnosis and alarm, operation data collection and analysis, to ensure the quality and performance of the product and ensure the safe operation of the screening machine.

Industries such as solid waste treatment, high-quality aggregates, dry mixed mortar, metallurgy (particle size grading), etc;

Aggregate and artificial sand making operations for various materials such as urban solid waste, hard limestone, river pebbles, and sand and gravel;

(1) Apply anti rust oil to the exposed processing surface to prevent corrosion.
(2) The handwriting on the product label should be clear and neat, firmly fixed, and not skewed.
(3) The painting color should comply with the provisions of JB229-78 “Painting Colors and Safety Signs for Mining, Engineering, and Crane Transport Machinery Products”. The painted surface shall not have defects such as unevenness, cracks, peeling, bubbles, and marks.

(1) The overall part of the product;
(2) Electric motors and motor mounts;
(3) Supporting device;
(4) Spare parts provided according to the order contract.
(5) The product should have reliability and durability in use.
(6) If the product is damaged or cannot function properly due to poor manufacturing quality within 12 months from the date of delivery, provided that the user complies with the storage and use rules (excluding vulnerable parts), the manufacturer shall repair and replace the product free of charge for the user.

(1) The experiment should comply with relevant regulations.
(2) The amplitude symmetry point error is less than 1.5mm.
(3) The noise is measured using a precision sound level meter, set at a distance of 1 meter from the sound source, and the average value is taken from at least three measuring points on each side.
(4) The bearing temperature is measured using a point thermometer.

(1) The quality inspection department of the manufacturing plant shall only allow the products to leave the factory after passing the inspection.
(2) Factory acceptance tests should be conducted.
(3) The factory acceptance test shall be conducted at the manufacturing plant, and the continuous air transportation shall not be less than 8 hours.
(4) The basic parameters should comply with the provisions in the previous table;
(5) The product performance meets the requirements of Article 4.6;
(6) Provide a certificate of conformity and inspection report for the spring according to 4.9;
(7) The appearance of the product should be inspected for quality according to clauses 4.11, 4.12, and 4.13.

(1) Each product should have a product label fixed in a prominent position, with the following content on the label
a. Manufacturer name;
b. Product name and model;
c. Main parameters of the product;
d. Trademark;
e. Date of manufacture and factory number.
(2) The packaging of the vibrating screen should comply with the provisions of JB/ZQ4286
(3) Electric motors, springs, spare parts, vulnerable parts, tools, and random documents sent to users should be packed in boxes.
(4) The random files are first packed with plastic tape and placed in the box. The files include:
a. Packing list;
b. Product qualification certificate;
c. Product manual;
d. Installation diagram;
e. Other relevant technical materials

The transportation of products should comply with the relevant requirements and regulations of the country and transportation departments.

(1) The vibrating screen should be stored in a dry and clean place, placed steadily, at a certain distance from the ground, and not stacked.
(2) When placed outdoors, measures should be taken to prevent exposure to rain, sun, and water.
(3) The product should be maintained once a year after storage.
